TECHNICAL DETAILS

ENGINE

DISPLACEMENT             168.9cc

STARTING TYPE              Electric/Kick

ENGINE STYLE                Single Cylinder, Air-cooled, 4-stroke

ENGINE MODEL              JJ1P161QMK

IGNITION                        CDI

CHASIS

DRY WEIGHT                   95 kg (209 lbs)

CROSS WEIGHT               135 kg (297 lbs)

MAX LOAD                        — kg (— lbs)

WHEELBASE                     1350 mm

FRONT TIRE                       120/90-10

REAR TIRE                         120/90-10

BRAKE STYLE                  Front: Disk, Rear: Drum

MAX. POWER                     8.3/8000 Kw/r/min

MAX. TORQUE                  11.0/6000 Nm/r/min

IMPRESSION RATIO    9.2:1

MAX. SPEED                       95 km/h (59 mph)
